Infinite Possibilities With
MIIN LASER
The Miin laser, developed through extensive research, is a versatile treatment for pigmented Lesions and also effectively addressed sensitive and demanding skin types by using a stable laser beam. It is known for its ability to minimize side effects while delivering positive results, particularly for various skin concerns.
MULTI-PULSE MIIN TONING
Generates 4 to 8 pulses at a maximum output power of 3,000mJ, It is a powerful and soft laser treatment that minimizes the side effects of laser.
Multi-Pulse Miin Toning
Using Nanogenesis Special Toning
By implementing the multi-pulse of nanoseconds using the active Q-switch method
Advanced laser technology specialized in minimizing side effects.
1064 Single
1064nm single pulse laser mode with 10 nanosecond
1064 Double
1064nm double pulsed laser with 100~150μs intervals
Miin Mode
1064nm multi-pulse laser at 25μs intervals
MIIN LASER
MLA Handpiece
Laser Induced Optical Breakdown (LIOB) using a handpiece with over 120 Micro Lens. It generates plasma under the skin. This plasma effect leads to restore damaged skin and repair acne scars to reduce pores to be smooth skin.
What is Micro Lens Array (MLA)?
A special honeycomb lens generates a plasma that rejuvenates the skin with the effect of skin regeneration.
What is Laser Induced Optical Breakdown (LIOB) effect?
Excellent for skin regeneration, scar reduction, pore improvement, and skin tone improvement by forming fine bubbles deep in the dermal layer without damaging the skin surface.
Special beam profile
LTRA Global’s special optical laser technology, which was born with years of research and development, is excellent for treating pigment lesions, enabling restoration of even damaged skin such as pigmentation.
Stable energy output
The constant output energy is maintained even for long-term laser treatment. The laser beam is irradiated steadily on sensitive and difficult skin, and it is challenged to zero side effects of laser treatment.
World-recognized technology
MIIN LASER
Approved by US 510K FDA, European medical device certification CE and KFDA Ministry of Food and Drug Safety
Q-Switched Nd:YAG Laser
From the deep dermis layer To Create Dazzling Skin
World best LASER SYSTEM
MLA Handpiece
It has excellent effect in recovering damaged skin by using a handpiece that equipped with 120 micro lens and creating fine bubbles in the dermis layer without harming skin surface.
Nanogenesis effect
Even after long-term laser treatment it has advantage of maintaining energy well to generate uniform output.
Wavelength
Q-switched Nd YAG laser with 1064nm/532nm wavelength is the most outstanding medical device and by using 10~25 nano second pulse width it can be best option for treating various pigments.
Beam Delivery System
Unlike the usual toning treatment regardless of shape and characteristics of melasma each part is treated differently and more effectively.
Pulse Energe
It generates 4~8 multiple pulses at a maximum energy of 3.000mJ Unlike usual toning it can be powerful and soft at the same time and minimize the side effect of laser treatment.
Aiming Beam
The constant output energy is maintained even atrer long-tern laser treatment.
BEFORE AND AFTER TREATMENTS - MIIN LASER
SPECIFICATION - MIIN LASER
| General | |
| Main Body Dimension (W x L x H) | 320 x 820 x 880 mm |
| Weight | 75 Kg |
| Main Voltage | 100 – 240VAC, 50/60Hz (Free Voltage) |
| Cooling System | Internal Water to Air Heat Exchanger |
| Laser System | |
| Laser Type | Q-switched Nd : YAG laser |
| Wavelength | 1064 / 532nm |
| Pulse Duration (nm) | 1064 Single, <10ns |
| 532, <10ns | |
| Quasi, 350us | |
| 1064 Double, <10ns | |
| Miin (Multi Pulse), <25ns | |
| Pulse Energy (Max.) | 1064 Single, 1.4J |
| 532, 0.5J | |
| Quasi, 3.5J | |
| 1064 Double, 2.5J | |
| Miin (Multi Pulse), 3.0J | |
| Repetition Rate | Single, 1 ~ 10Hz |
| Handpiece | |
| Beam Delivery System | Articulated Arm with Handpiece |
| Aiming Beam | Laser diode, 633nm / 3mW |
